Industrial Evaporative Cooling for Restaurants

Evaporative Cooling System Industrial Evaporative Cooling for Restaurants Evaporative Cooling System Industrial Evaporative Cooling for Restaurants Evaporative Cooling System Industrial Evaporative Cooling for Restaurants

Add to Cart

If you have a detailed purchasing list, please contact us directly with attachments.

Model: ecs03

Air Volume:13000 m³/h

Maximum Air Pressure: 295 Pa

Maximum Power: 2.5 KW, 380 V

Water Consumption: 17 L/h

Air Distribution Distance(m): ≤45

Suggested Number of Spherical Air Diffusers with a Diameter of 85mm: 25-30 units

Air Outlet Dimension(mm): 431*375

Overall Dimension(L*W*H mm): 1250*960*776

Net Weight(kg): 115

Applicable Industries: Commercial Kitchens,Renovated Kitchens,Open Kitchen Designs,Food Processing Facilities,Cafeterias and Buffet Areas,Food Trucks and Mobile Kitchens,Hotels,Industry

Overview

Evaporative cooling systems are essential in commercial kitchens, where high temperatures can significantly impact both comfort and food safety. These systems effectively lower the ambient temperature, creating a more pleasant working environment for chefs and kitchen staff. By utilizing a natural cooling process, it helps to reduce heat generated by cooking appliances, thus improving overall workplace efficiency.

In renovated kitchens, particularly those that were initially designed without adequate cooling solutions, installing an evaporative cooling system can be a game changer. It provides a cost-effective way to manage heat levels, ensuring the kitchen remains cool and comfortable during peak cooking times. This addition not only enhances the modernity and functionality of the kitchen but also improves energy efficiency compared to traditional air conditioning systems.

Standard Features

Intelligent Control System: Automatically adjusts humidity levels for optimal comfort.Comes with a standard electrical box and touch screen panel that displays temperature control, motor thermal protection, filter blockage alarm, gas alarm emergency interface, and supports auto-start on power failure.

Filtration Protection Features: The filter prevents insects and dust, equipped with blockage alarm prompts.

Efficient Cooling Principle: The water-cooled fresh air unit cools the air by evaporating a small amount of water. At 35℃/60% humidity, it can cool the incoming air to a minimum of 29.6℃ and filters out debris to prevent contamination of food.

Comprehensive Protection Device: The motor has a comprehensive protection device, including a thermal protection switch within the enamelled wire, with complete gas linkage and 485 interface protections.

Innovative Watering Principle: Utilizes an intermittent watering principle, preventing dirty water circulation and avoiding maintenance issues with floats, pumps, and drainage valves.

High-Quality Fan: Uses Yilida external rotor centrifugal fan with no belts and original NSK bearings from Japan, requiring no oiling or maintenance.

Durable Materials: Cooling sections are made from special engineering plastics, injection molded with no seams, ensuring they never rust.

Easy Installation: Installation requires only connecting to a power source, 4-inch water supply, and draining to a floor drain for immediate use.

Function

Significant Cooling Effect:Experience a substantial drop in temperature for ultimate comfort.

Low Investment:Affordable solution for both new and existing kitchen projects.

Low Energy Consumption:Save on energy bills while improving air quality.

Easy Installation:Quick and hassle-free setup for your kitchen renovation.

Ideal for New Kitchen Projects:Perfect for enhancing modern kitchen designs.

Kitchen Renovations:Upgrade your kitchen with our efficient air supply system.

Retrofitting Old Air Systems:Transform your outdated air supply system with our advanced technology.

Optional Features

The optional configurations include different Air Volume (CMH) based on airflow capacity, specially designed for optimal cooling in commercial kitchens.
